Johnson Controls VG1245CP+923BUB Ball Valve with Electric Actuator Price Drop

The Johnson Controls VG1245CP+923BUB Ball Valve with Electric Actuator is designed to regulate the flow of hot or chilled water and low-pressure steam in HVAC systems. This valve features a forged brass body with a static pressure rating of 580 psig. The model VA9203-BUB-2 open spring-return electric actuator ensures precise control.

• Two-way stainless steel ball valve
• Includes open spring-return electric actuator
• Regulates hot or chilled water and low-pressure steam

Product Highlights

Enhance your HVAC system with the Johnson Controls VG1245CP+923BUB Ball Valve, designed for precise flow control in various applications.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VG1245CP+923BUB
• Model: VG1245CP
• Manufacturer: Johnson Controls, Inc

Technical Specifications

• Body Material: Forged Brass
• Pressure Rating: 580 psig
• Valve Type: Two-way
• Actuator Type: Electric, open spring-return
• Flow Control: On/off, floating, or proportional
• Voltage: 85-264V
• Cv: 18.7
