Fireye 95DSS3-1 Insight II Flame Scanner – Integrated IR and UV Sensors Professional Grade

The Fireye Insight II model 95DSS3-1 is a dual-sensor flame scanner, integrating infrared and ultraviolet technologies to deliver accurate flame discrimination. This makes it a vital component in complex multi-burner environments or close single burner configurations. Designed for high safety and operational efficiency, it eliminates the need for separate remote flame amplifiers.

• Combines IR and UV sensors for reliable detection.
• Includes dual flame relays and dual 4-20 mA outputs.
• UL-certified to Safety Integrity Level 3 (SIL3) for optimum safety.

Product Highlights

Designed for rugged industrial environments, this scanner features quick installation capabilities due to its integrated design. It effectively reduces system complexity and enhances maintenance efficiency. Excellent for applications in boilers and furnaces within hazardous locations classified Class I, Div 2, Groups A-D and Class II, Div 2, Groups F-G.

Product Information

Technical Specifications

• Brand: Fireye
• MPN: 95DSS3-1
• Product Type: Mechanical Components
• Category: HVAC Equipment
• Approvals: Class I, Div 2, Groups A-D; Class II, Div 2, Groups F-G
• Safety Certification: UL Certified to SIL3
• Output: Dual 4-20 mA analog outputs
• Flame Relays: Two internal with adjustable On/Off thresholds
