Certified EATON C25DNF240A Definite Purpose Contactor 40A 2 Pole 120VAC

The EATON C25DNF240A is a robust, non-reversing definite purpose AC contactor designed for optimized performance in the HVAC industry. Integral to controlling electric motors and other high-power loads, this contactor operates reliably within a voltage range of 110 to 120 VAC and is capable of handling up to 40 A inductive and 50 A resistive loads.

• Rated for 40 A inductive and 50 A resistive loads.
• 2-pole configuration with double-break contact type.
• Quick-connect side-by-side connections and box lug terminals.

Product Highlights

This contactor features a robust open enclosure and a built-in metal mounting plate for easy installation. Its compact dimensions (3.35 in L x 2.4 in W x 3.75 in H) make it suitable for confined spaces, enhancing its versatility across various applications.

Product Information

Standard Information

• Operating Temperature: 150 degrees Fahrenheit ambient.
• Connection Type: Quick-Connect (Side by Side).

Technical Specifications

• Coil Voltage: 110 to 120 VAC.
• Frequency Rating: 50/60 Hz.
• Dimensions: 3.35 in Length x 2.4 in Width x 3.75 in Height.
• Contact Type: Double Break.
• Enclosure Type: Open with metal mounting plate.
• Terminal Type: Box Lug (Posidrive Setscrew).
• Number of Poles: 2.
• Maximum Load Current: 40 A Inductive, 50 A Resistive.
