ASCO 8210G095 General Service Solenoid Valve 120VAC 3/4 Inch NPT Sale

The ASCO 8210G095 is a general service solenoid valve designed for reliable fluid control in various industrial applications. This valve operates at 120 volts alternating current and has a two-way design suitable for controlling the flow of air, water, light oil, and other non-corrosive fluids. The valve features a 3/4-inch NPT connection, ensuring secure installation with minimal leaks.

• 120 VAC, Normally Closed, 3/4 inch NPT connection
• High flow rate supported with a Cv of 5
• Durable brass construction for long service life

Product Highlights

This solenoid valve is built for enhanced performance in demanding environments. Its robust design and efficient operation make it suitable for applications such as car washes, air compressors, and industrial water control.

Product Information

Standard Information

• Brand: ASCO
• Model Number: 8210G095

Technical Specifications

• Voltage: 120 VAC
• Pipe Size: 3/4 inch
• Pressure Rating: 0 to 150 PSI
• Flow Coefficient (Cv): 5
• Seal Material: NBR
• End Connection: NPT
• Actuator Type: Pilot Operated
• Dimensions: 2.29 inches wide x 4.13 inches high
